yz 125a 453-007803

Saturday, June 21, 2008

Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa
Posted by Picasa

Saturday, June 14, 2008

Firing the engine.

Firing the engine.
Saturday 14/6/08 Fuel and get started.
The engine fired up on about kick 4 very happy with that.
Engine runs nicely . No excessive revs due to having new ring.
Developed a weeping fuel leak at the float bowl join after 10 minutes .
Yet to rectify, other than that all A ok.

Friday, June 13, 2008

Friday, May 9, 2008

Friday, January 4, 2008

Electrical system YZ A

Ok what can be used for 125a electrical.
The YZ 125 C will not fit as the width is to wide.
The CDI box is the same part number for both the YZ 125C and the yz125A (PN/364-85540-13-00) So if you can modify the overall thickness of the 125c stator it should work.Note the below pictures are of a YZ125A stator.
The PN/for YZ 125A 537-85500-10-00C.D.I. MAGNETO ASS'Y

YZ 125 A stator thickness (58mm) RH photo click on image to enlarge.

Friday, December 28, 2007

Friday, December 7, 2007

Saturday, November 10, 2007

Saturday, November 3, 2007

Wednesday, September 12, 2007

Parts required

1. Seat 401-24770-00-00 NOS Located

2. Seat cover 401-24771-00-00 Located

3. Exhaust 401-14610-01-00 EXHAUST PIPE ASS'Y NOS Located

4. STAY, MUFFLER 401-14771-00-00 STAY, MUFFLER NOS Located

5. Handle bars 401-26111-01-00 HANDLE used Located

6. Lever RH 583-83922-30-00 LEVER, RIGHT (233-83922-31) NOS Located

7. Lever LH 583-83912-10-00 LEVER, LEFT NOS Located

8. 214-82911-01-00 HOLDER, LEVER LEFT NOS Located

9. 233-82921-31-00 HOLDER, LEVER RIGHT NOS Located

10.GRIP, RIGHT 583-26242-00-00 GRIP, RIGHT no

11.GRIP, LEFT 583-26241-00-00 GRIP, LEFT no

12.SWITCH, HANDLE 363-83976-01-00 SWITCH, HANDLE 1 NOS Located

13.WIRE, CLUTCH 401-26335-03-00 WIRE, CLUTCH NOS Located

14.WIRE, BRAKE FRONT 427-26341-00-00 WIRE, BRAKE FRONT NOS Located

15. 345-25104-01-00 SPOKE SET NOS Located

16.318-23487-00-00 STAY, PLATE NOS Located

17.90146-06007-00 SCREW (322-23396-00) 2 OF THESE NOS Located

18. washer plate located

19.322-23319-00-00 WIRE, HOLDER NOS Located

20.95303-06600-00 NUT 2 OF THESE NOS Located

21.401-14453-00-00 JOINT, AIR CLEANER NOS Located

22.401-14412-00-00 CAP, CASE Located

23.90460-54062-00 CLAMP, HOSE (308-14455-00) Located

24.90460-43053-00 CLAMP, HOSE (304-14455-70) Located

Saturday, September 8, 2007

Paint stripper

All the paint removed and now the rust is exposed, easy fix bead blast or chemical clean.
I will be chemically cleaning.
The reason I prefer this is you don't run the risk of blasting particals lodging in the paint surface, no matter how well you blow the frame out there will nearly always be some particals left.

Saturday, September 1, 2007

Electrical system YZ A -B- C

The YZ 125A&B prefix 453 have the same electrical CDI
CDI part number 364-85540-13-00

Unrestored condition 33years on.
